Peavey 4XT Horn Driver

Price: $50.00

In Stock

Email this page to a friend

- 1.4"
- Throat Parameter: 1" / 25 mm
- Nominal Impedance: 8 Ohms
- Minimum Impedance: 7.1 Ohms
- DC Resistance: 6.8 Ohms
- Power Capacity 1000 Hz to 20,000 Hz: 100 W peak 50 W program 25 W continuous
- Sensitivity: 102 dB SPL 1 Watt at 1 meter On-axis on 90º H x 45º V horn
- Nominal Efficiency: 30%
- Frequency Response: 1 kHz to 18,000 Hz
- Recommended Crossover: 1,800 Hz at 12 dB / Octave
- Lowest Recommended Crossover: 1,000 Hz at 12 dB / Octave
- Diaphragm: Commercially pure titanium
- Voice Coil Diameter: 1.4" / 35.5 mm
- Voice Coil Material: Edge-wound ribbon with high temp Kapton bobbin
- Flux Density: 11,500 gauss (1.15T)
- Dimensions: 3.500" (91.44 mm) diameter x 2.75" (69.85 mm) depth
- Horn Coupling Diameter: 1.0" (25.4 mm)
- Horn Coupling Threads: Standard 1 3/8" - 18"
- Net Weight: 33.3 oz.
- Shipping Weight: 37 oz.
- Weight Unpacked: 2.05 lb(0.928 kg)
- Weight Packed: 2.16 lb(0.982 kg)
- Width Packed: 3.75"(9.525 cm)
- Height Packed: 3.75"(9.525 cm)
- Depth Packed: 3.25"(8.255 cm)
